PortuguêsHeavy Duty Rubber Belt Winder For 6 Tons Roll
This heavy-duty winder boasts a max load capacity of 6 tons and max roll height of 2 meters, ideal for winding all conveyor belt types (PVC, PU, PVK, rubber) and non-woven fabrics.
Technical Datasheet:
| Model :CAW200E | 2000mm Heavy-duty Belt Winder |
| Dimension | 3890*2280*2150mm |
| Power | 7.5kw |
| Suggested Voltage | 380v 3phase (or as your request) |
| Max Belt Width | 2000mm(78' ') |
| Max Belt Roll Diameter | 3000mm(118' ') |
| Max Speed | 10M/min (with speed regulator) |
| Speed Ratio | 1/136 |
| Rated Torque | 6493 N.m |
| Load Capacity | 7 Tons |
Product Features:
- Max load capacity is 6 tons, max roll height is 2 meters.
- Winder for all types conveyor belt (PVC, PU, PVK, Rubber conveyor belt and non-woven fabrics).
- Units are designed for years of reliable trouble-free operation.
- According to different working requirements, the roll speed can be adjusted.
- The winder and the machine are controlled by a main motor, with stable speed and good performance.
